Effects

Effects are used in OpenShot to enhance or modify the audio or video of a clip. They can modify pixels and audio data, and can generally enhance your video projects. Each effect has its own set of properties, most of which can be animated over time, for example varying the Brightness & Contrast of a clip over time.

Effects can be added to any clip by dragging and dropping them from the Effects tab onto a clip. Each effect is represented by a small colored icon and the first letter of the effect name. Note: Pay close attention to where the play-head (i.e. red playback line) is. Key frames are automatically created at the current playback position, to help create animations quickly.

To view an effect’s properties, right-click on the effect icon, revealing the context menu, and choose Properties. The property editor will appear, where you can edit these properties. Properties appear alphabetically in the dock, with filter options available at the top. See Clip Properties.

To adjust a property:

  • Drag the slider for coarse changes.

  • Double-click to enter precise values.

  • Right/double-click for non-numerical options.

Effect properties are integral to the Animation system. When you modify an effect property, a keyframe is generated at the current playhead position. For a property to span the entire clip, position the playhead at or before the clip’s start before making adjustments. A convenient way to identify a clip’s start is by utilizing the ‘next/previous marker’ feature on the Timeline toolbar.

_images/clip-effects.jpg

List of Effects

OpenShot Video Editor has a total of 27 built-in video and audio effects: 18 video effects and 9 audio effects. These effects can be added to a clip by dragging the effect onto a clip. The following table contains the name and short description of each effect.

Effect Name

Effect Description

Alpha Mask / Wipe Transition

Grayscale mask transition between images.

Bars

Add colored bars around your video.

Blur

Adjust image blur.

Brightness & Contrast

Modify frame’s brightness and contrast.

Caption

Add text captions to any clip.

Chroma Key (Greenscreen)

Replace color with transparency.

Color Saturation

Adjust color intensity.

Color Shift

Shift image colors in various directions.

Crop

Crop out parts of your video.

Deinterlace

Remove interlacing from video.

Hue

Adjust hue / color.

Negative

Produce a negative image.

Object Detector

Detect objects in video.

Pixelate

Increase or decrease visible pixels.

Shift

Shift image in different directions.

Stabilizer

Reduce video shake.

Tracker

Track bounding box in video.

Wave

Distort image into a wave pattern.

Compressor

Reduce loudness or amplify quiet sounds.

Delay

Adjust audio-video synchronism.

Distortion

Clip audio signal for distortion.

Echo

Add delayed sound reflection.

Expander

Make loud parts relatively louder.

Noise

Add random equal-intensity signals.

Parametric EQ

Adjust frequency volume in audio.

Robotization

Transform audio into robotic voice.

Whisperization

Transform audio into whispers.

Effect Properties

Below is a list of common effect properties, shared by all effects in OpenShot. To view an effect’s properties, right click and choose Properties. The property editor will appear, where you can change these properties. Note: Pay close attention to where the play-head (i.e. red playback line) is. Key frames are automatically created at the current playback position, to help quickly create animations.

See the table below for a list of common effect properties. Only the common properties that all effects share are listed here. Each effect also has many unique properties, which are specific to each effect, see Video Effects for more information on individual effects and their unique properties.

Effect Property Name

Type

Description

Duration

Float

The length of the effect (in seconds). Read-only property. Most effects default to the length of a clip. This property is hidden when an effect belongs to a clip.

End

Float

The end trimming position of the effect (in seconds). This property is hidden when an effect belongs to a clip.

ID

String

A randomly generated GUID (globally unique identifier) assigned to each effect. Read-only property.

Parent

String

The parent object to this effect, which makes many of these keyframe values initialize to the parent value.

Position

Float

The position of the effect on the timeline (in seconds). This property is hidden when an effect belongs to a clip.

Start

Float

The start trimming position of the effect (in seconds). This property is hidden when an effect belongs to a clip.

Track

Int

The layer which holds the effect (higher tracks are rendered on top of lower tracks). This property is hidden when an effect belongs to a clip.

Apply Before Clip

Boolean

Apply this effect before the Clip processes keyframes? (default is Yes)

Duration

The Duration property is a float value indicating the length of the effect in seconds. This is a Read-only property. This is calculated by: End - Start. To modify duration, you must edit the Start and/or End effect properties.

NOTE: Most effects in OpenShot default the effect duration to the clip duration, and hide this property from the editor.

End

The End property defines the trimming point at the end of the effect in seconds, allowing you to control how much of the effect is visible in the timeline. Changing this property will impact the Duration effect property.

NOTE: Most effects in OpenShot default this property to match the clip, and hide this property from the editor.

ID

The ID property holds a randomly generated GUID (Globally Unique Identifier) assigned to each effect, ensuring its uniqueness. This is a Read-only property, and assigned by OpenShot when an effect is created.

Track

The Track property is an integer indicating the layer on which the effect is placed. Effects on higher tracks are rendered above those on lower tracks.

NOTE: Most effects in OpenShot default this property to match the clip, and hide this property from the editor.

Effect Parent

The Parent property of an effect sets the initial keyframe values to a parent effect. For example, if many effects all point to the same parent effect, they will inherit all their initial properties, such as font size, font color, and background color for a Caption effect. In the example of many Caption effects using the same Parent effect, it is an efficient way to manage a large number of these effects.

NOTE: The parent property for effects should be linked to the same type of parent effect, otherwise their default initial values will not match. Also see Clip Parent.

Position

The Position property determines the effect’s position on the timeline in seconds, with 0.0 indicating the beginning.

NOTE: Most effects in OpenShot default this property to match the clip, and hide this property from the editor.

Start

The Start property defines the trimming point at the beginning of the effect in seconds. Changing this property will impact the Duration effect property.

NOTE: Most effects in OpenShot default this property to match the clip, and hide this property from the editor.

Sequencing

Effects are normally applied before the Clip processes keyframes. This allows the effect to process the raw image of the clip, before the clip applies properties such as scaling, rotation, location, etc… Normally, this is the preferred sequence of events, and this is the default behavior of effects in OpenShot. However, you can optionally override this behavior with the Apply Before Clip Keyframes property.

If you set the Apply Before Clip Keyframes property to No, the effect will be sequenced after the clip scales, rotates, and applies keyframes to the image. This can be useful on certain effects, such as the Mask effect, when you want to animate a clip first and then apply a static mask to the clip.

Video Effects

Effects are generally divided into two categories: video and audio effects. Video effects modify the image and pixel data of a clip. Below is a list of video effects, and their properties. Often it is best to experiment with an effect, entering different values into the properties, and observing the results.

Alpha Mask / Wipe Transition

The Alpha Mask / Wipe Transition effect leverages a grayscale mask to create a dynamic transition between two images or video clips. In this effect, the light areas of the mask reveal the new image, while the dark areas conceal it, allowing for creative and custom transitions that go beyond standard fade or wipe techniques. This effect only affects the image, and not the audio track.

Property Name

Description

brightness

(float, -1 to 1) This curve controls the motion across the wipe

contrast

(float, 0 to 20) This curve controls the hardness and softness of the wipe edge

reader

(reader) This reader can use any image or video as input for your grayscale wipe

replace_image

(bool, choices: ['Yes', 'No']) Replace the clips image with the current grayscale wipe image, useful for troubleshooting

Bars

The Bars effect adds colored bars around your video frame, which can be used for aesthetic purposes, to frame the video within a certain aspect ratio, or to simulate the appearance of viewing content on a different display device. This effect is particularly useful for creating a cinematic or broadcast look.

Property Name

Description

bottom

(float, 0 to 0.5) The curve to adjust the bottom bar size

color

(color) The curve to adjust the color of bars

left

(float, 0 to 0.5) The curve to adjust the left bar size

right

(float, 0 to 0.5) The curve to adjust the right bar size

top

(float, 0 to 0.5) The curve to adjust the top bar size

Blur

The Blur effect softens the image, reducing detail and texture. This can be used to create a sense of depth, draw attention to specific parts of the frame, or simply to apply a stylistic choice for aesthetic purposes. The intensity of the blur can be adjusted to achieve the desired level of softness.

Property Name

Description

horizontal_radius

(float, 0 to 100) Horizontal blur radius keyframe. The size of the horizontal blur operation in pixels.

iterations

(float, 0 to 100) Iterations keyframe. The # of blur iterations per pixel. 3 iterations = Gaussian.

sigma

(float, 0 to 100) Sigma keyframe. The amount of spread in the blur operation. Should be larger than radius.

vertical_radius

(float, 0 to 100) Vertical blur radius keyframe. The size of the vertical blur operation in pixels.

Brightness & Contrast

The Brightness & Contrast effect allows for the adjustment of the overall lightness or darkness of the image (brightness) and the difference between the darkest and lightest parts of the image (contrast). This effect can be used to correct poorly lit videos or to create dramatic lighting effects for artistic purposes.

Property Name

Description

brightness

(float, -1 to 1) The curve to adjust the brightness

contrast

(float, 0 to 100) The curve to adjust the contrast (3 is typical, 20 is a lot, 100 is max. 0 is invalid)

Caption

Add text captions on top of your video. We support both VTT (WebVTT) and SubRip (SRT) subtitle file formats. These formats are used to display captions or subtitles in videos. They allow you to add text-based subtitles to video content, making it more accessible to a wider audience, especially for those who are deaf or hard of hearing. The Caption effect can even animate the text fading in/out, and supports any font, size, color, and margin. OpenShot also has an easy-to-use Caption editor, where you can quickly insert captions at the playhead position, or edit all your caption text in one place.

:caption: Show a caption, starting at 5 seconds and ending at 10 seconds.

00:00:05.000 --> 00:00:10.000
Hello, welcome to our video!

Property Name

Description

background

(color) Color of caption area background

background_alpha

(float, 0 to 1) Background color alpha

background_corner

(float, 0 to 60) Background corner radius

background_padding

(float, 0 to 60) Background padding

caption_font

(font) Font name or family name

caption_text

(caption) VTT/Subrip formatted caption text (multi-line)

color

(color) Color of caption text

fade_in

(float, 0 to 3) Fade in per caption (# of seconds)

fade_out

(float, 0 to 3) Fade out per caption (# of seconds)

font_alpha

(float, 0 to 1) Font color alpha

font_size

(float, 0 to 200) Font size in points

left

(float, 0 to 0.5) Size of left margin

line_spacing

(float, 0 to 5) Distance between lines (1.0 default)

right

(float, 0 to 0.5) Size of right margin

stroke

(color) Color of text border / stroke

stroke_width

(float, 0 to 10) Width of text border / stroke

top

(float, 0 to 1) Size of top margin

Chroma Key (Greenscreen)

The Chroma Key (Greenscreen) effect replaces a specific color (or chroma) in the video (commonly green or blue) with transparency, allowing for the compositing of the video over a different background. This effect is widely used in film and television production for creating visual effects and placing subjects in settings that would be otherwise impossible or impractical to shoot in.

Property Name

Description

color

(color) The color to match

threshold

(float, 0 to 125) The threshold (or fuzz factor) for matching similar colors. The larger the value the more colors that will be matched.

halo

(float, 0 to 125) The additional threshold for halo elimination.

keymethod

(int, choices: ['Basic keying', 'HSV/HSL hue', 'HSV saturation', 'HSL saturation', 'HSV value', 'HSL luminance', 'LCH luminosity', 'LCH chroma', 'LCH hue', 'CIE Distance', 'Cb,Cr vector']) The keying method or algorithm to use.

Color Saturation

The Color Saturation effect adjusts the intensity and vibrancy of colors within the video. Increasing saturation can make colors more vivid and eye-catching, while decreasing it can create a more subdued, almost black-and-white appearance.

Property Name

Description

saturation

(float, 0 to 4) The curve to adjust the overall saturation of the frame’s image (0.0 = greyscale, 1.0 = normal, 2.0 = double saturation)

saturation_B

(float, 0 to 4) The curve to adjust blue saturation of the frame’s image

saturation_G

(float, 0 to 4) The curve to adjust green saturation of the frame’s image (0.0 = greyscale, 1.0 = normal, 2.0 = double saturation)

saturation_R

(float, 0 to 4) The curve to adjust red saturation of the frame’s image

Color Shift

Shift the colors of an image up, down, left, and right (with infinite wrapping).

Each pixel has 4 color channels:

  • Red, Green, Blue, and Alpha (i.e. transparency)

  • Each channel value is between 0 and 255

The Color Shift effect simply “moves” or “translates” a specific color channel on the X or Y axis. Not all video and image formats support an alpha channel, and in those cases, you will not see any changes when adjusting the color shift of the alpha channel.

Property Name

Description

alpha_x

(float, -1 to 1) Shift the Alpha X coordinates (left or right)

alpha_y

(float, -1 to 1) Shift the Alpha Y coordinates (up or down)

blue_x

(float, -1 to 1) Shift the Blue X coordinates (left or right)

blue_y

(float, -1 to 1) Shift the Blue Y coordinates (up or down)

green_x

(float, -1 to 1) Shift the Green X coordinates (left or right)

green_y

(float, -1 to 1) Shift the Green Y coordinates (up or down)

red_x

(float, -1 to 1) Shift the Red X coordinates (left or right)

red_y

(float, -1 to 1) Shift the Red Y coordinates (up or down)

Crop

The Crop effect removes unwanted outer areas from the video frame, allowing you to focus on a particular part of the shot, change the aspect ratio, or remove distracting elements from the edges of the frame. This effect is the primary method for cropping a Clip in OpenShot. The left, right, top, and bottom key-frames can even be animated, for a moving and resizing cropped area. You can leave the cropped area blank, or you can dynamically resize the cropped area to fill the screen.

Property Name

Description

bottom

(float, 0 to 1) Size of bottom bar

left

(float, 0 to 1) Size of left bar

right

(float, 0 to 1) Size of right bar

top

(float, 0 to 1) Size of top bar

x

(float, -1 to 1) X-offset

y

(float, -1 to 1) Y-offset

resize

(bool, choices: ['Yes', 'No']) Replace the frame image with the cropped area (allows automatic scaling of the cropped image)

Deinterlace

The Deinterlace effect is used to remove interlacing artifacts from video footage, which are commonly seen as horizontal lines across moving objects. This effect is essential for converting interlaced video (such as from older video cameras or broadcast sources) into a progressive format suitable for modern displays.

Property Name

Description

isOdd

(bool, choices: ['Yes', 'No']) Use odd or even lines

Hue

The Hue effect adjusts the overall color balance of the video, changing the hues without affecting the brightness or saturation. This can be used for color correction or to apply dramatic color effects that transform the mood of the footage.

Property Name

Description

hue

(float, 0 to 1) The curve to adjust the percentage of hue shift

Negative

The Negative effect inverts the colors of the video, producing an image that resembles a photographic negative. This can be used for artistic effects, to create a surreal or otherworldly look, or to highlight specific elements within the frame.

Object Detector

The Object Detector effect employs machine learning algorithms (such as neural networks) to identify and highlight objects within the video frame. It can recognize multiple object types, such as vehicles, people, animals, and more! This can be used for analytical purposes, to add interactive elements to videos, or to track the movement of specific objects across the frame.

Class Filters & Confidence

To adjust the detection process to your specific needs, the Object Detector includes properties for class filters and confidence thresholds. By setting a class filter, such as “Truck” or “Person,” you can instruct the detector to focus on specific types of objects, limiting the types of objects tracked. The confidence threshold allows you to set a minimum level of certainty for detections, ensuring that only objects detected with a confidence level above this threshold are considered, which helps in reducing false positives and focusing on more accurate detections.

How Parenting Works

Once you have tracked objects, you can “parent” other Clips to them. This means that the second clip, which could be a graphic, text, or another video layer, will now follow the tracked object as if it’s attached to it. If the tracked object moves to the left, the child clip moves to the left. If the tracked object grows in size (gets closer to the camera), the child clip also scales up. For parented clips to appear correctly, they must be on a Track higher than the tracked objects, and set the appropriate Scale property.

See Clip Parent.

Properties

Property Name

Description

class_filter

(string) Type of object class to filter (i.e. car, person)

confidence_threshold

(float, 0 to 1) Minimum confidence value to display the detected objects

display_box_text

(int, choices: ['Yes', 'No']) Draw class name and ID of ALL tracked objects

display_boxes

(int, choices: ['Yes', 'No']) Draw bounding box around ALL tracked objects (a quick way to hide all tracked objects)

selected_object_index

(int, 0 to 200) Index of the tracked object that is selected to modify its properties

draw_box

(int, choices: ['Yes', 'No']) Whether to draw the box around the selected tracked object

box_id

(string) Internal ID of a tracked object box for identification purposes

x1

(float, 0 to 1) Top left X coordinate of a tracked object box, normalized to the video frame width

y1

(float, 0 to 1) Top left Y coordinate of a tracked object box, normalized to the video frame height

x2

(float, 0 to 1) Bottom right X coordinate of a tracked object box, normalized to the video frame width

y2

(float, 0 to 1) Bottom right Y coordinate of a tracked object box, normalized to the video frame height

delta_x

(float, -1.0 to 1) Horizontal movement delta of the tracked object box from its previous position

delta_y

(float, -1.0 to 1) Vertical movement delta of the tracked object box from its previous position

scale_x

(float, 0 to 1) Scaling factor in the X direction for the tracked object box, relative to its original size

scale_y

(float, 0 to 1) Scaling factor in the Y direction for the tracked object box, relative to its original size

rotation

(float, 0 to 360) Rotation angle of the tracked object box, in degrees

visible

(bool) Is the tracked object box visible in the current frame. Read-only property.

stroke

(color) Color of the stroke (border) around the tracked object box

stroke_width

(int, 1 to 10) Width of the stroke (border) around the tracked object box

stroke_alpha

(float, 0 to 1) Opacity of the stroke (border) around the tracked object box

background_alpha

(float, 0 to 1) Opacity of the background fill inside the tracked object box

background_corner

(int, 0 to 150) Radius of the corners for the background fill inside the tracked object box

background

(color) Color of the background fill inside the tracked object box

Pixelate

The Pixelate effect increases or decreases the size of the pixels in the video, creating a mosaic-like appearance. This can be used to obscure details (such as faces or license plates for privacy reasons), or as a stylistic effect to evoke a retro, digital, or abstract aesthetic.

Property Name

Description

bottom

(float, 0 to 1) The curve to adjust the bottom margin size

left

(float, 0 to 1) The curve to adjust the left margin size

pixelization

(float, 0 to 0.99) The curve to adjust the amount of pixelization

right

(float, 0 to 1) The curve to adjust the right margin size

top

(float, 0 to 1) The curve to adjust the top margin size

Shift

The Shift effect moves the entire image in different directions (up, down, left, and right with infinite wrapping), creating a sense of motion or disorientation. This can be used for transitions, to simulate camera movement, or to add dynamic motion to static shots.

Property Name

Description

x

(float, -1 to 1) Shift the X coordinates (left or right)

y

(float, -1 to 1) Shift the Y coordinates (up or down)

Stabilizer

The Stabilizer effect reduces unwanted shake and jitter in handheld or unstable video footage, resulting in smoother, more professional-looking shots. This is particularly useful for action scenes, handheld shots, or any footage where a tripod was not used.

Property Name

Description

zoom

(float, 0 to 2) Percentage to zoom into the clip, to crop off the shaking and uneven edges

Tracker

The Tracker effect allows for the tracking of a specific object or area within the video frame across multiple frames. This can be used for motion tracking, adding effects or annotations that follow the movement of objects, or for stabilizing footage based on a tracked point.When tracking an object, be sure to select the entire object, which is visible at the start of a clip, and choose one of the following Tracking Type algorithms. The tracking algorithm then follows this object from frame to frame, recording its position, scale, and sometimes rotation.

Tracking Type

  • KCF: (default) A blend of Boosting and MIL strategies, employing correlation filters on overlapping areas from ‘bags’ to accurately track and predict object movement. It offers higher speed and accuracy and can stop tracking when the object is lost but struggles to resume tracking after losing the object.

  • MIL: Improves upon Boosting by considering multiple potential positives (‘bags’) around the definite positive object, increasing robustness to noise and maintaining good accuracy. However, it shares the Boosting Tracker’s drawbacks of low speed and difficulty in stopping tracking when the object is lost.

  • BOOSTING: Utilizes the online AdaBoost algorithm to enhance the classification of tracked objects by focusing on incorrectly classified ones. It requires setting the initial frame and treats nearby objects as background, adjusting to new frames based on maximum score areas. It’s known for accurate tracking but suffers from low speed, noise sensitivity, and difficulty stopping tracking upon object loss.

  • TLD: Decomposes tracking into tracking, learning, and detection phases, allowing for adaptation and correction over time. While it can handle object scaling and occlusions reasonably well, it may behave unpredictably, with instability in tracking and detection.

  • MEDIANFLOW: Based on the Lucas-Kanade method, it analyzes forward and backward movement to estimate trajectory errors for real-time position prediction. It’s fast and accurate under certain conditions but can lose track of fast-moving objects.

  • MOSSE: Utilizes adaptive correlations in Fourier space to maintain robustness against lighting, scale, and pose changes. It boasts very high tracking speeds and is better at continuing tracking after loss, but it may persist in tracking an absent object.

  • CSRT: Employs spatial reliability maps to adjust filter support, enhancing the ability to track non-rectangular objects and perform well even with object overlaps. However, it is slower and may not operate reliably when the object is lost.

How Parenting Works

Once you have a tracked object, you can “parent” other Clips to it. This means that the second clip, which could be a graphic, text, or another video layer, will now follow the tracked object as if it’s attached to it. If the tracked object moves to the left, the child clip moves to the left. If the tracked object grows in size (gets closer to the camera), the child clip also scales up. For parented clips to appear correctly, they must be on a Track higher than the tracked objects, and set the appropriate Scale property.

See Clip Parent.

Properties

Property Name

Description

draw_box

(int, choices: ['Yes', 'No']) Whether to draw the box around the tracked object

box_id

(string) Internal ID of a tracked object box for identification purposes

x1

(float, 0 to 1) Top left X coordinate of a tracked object box, normalized to the video frame width

y1

(float, 0 to 1) Top left Y coordinate of a tracked object box, normalized to the video frame height

x2

(float, 0 to 1) Bottom right X coordinate of a tracked object box, normalized to the video frame width

y2

(float, 0 to 1) Bottom right Y coordinate of a tracked object box, normalized to the video frame height

delta_x

(float, -1.0 to 1) Horizontal movement delta of the tracked object box from its previous position

delta_y

(float, -1.0 to 1) Vertical movement delta of the tracked object box from its previous position

scale_x

(float, 0 to 1) Scaling factor in the X direction for the tracked object box, relative to its original size

scale_y

(float, 0 to 1) Scaling factor in the Y direction for the tracked object box, relative to its original size

rotation

(float, 0 to 360) Rotation angle of the tracked object box, in degrees

visible

(bool) Is the tracked object box visible in the current frame. Read-only property.

stroke

(color) Color of the stroke (border) around the tracked object box

stroke_width

(int, 1 to 10) Width of the stroke (border) around the tracked object box

stroke_alpha

(float, 0 to 1) Opacity of the stroke (border) around the tracked object box

background_alpha

(float, 0 to 1) Opacity of the background fill inside the tracked object box

background_corner

(int, 0 to 150) Radius of the corners for the background fill inside the tracked object box

background

(color) Color of the background fill inside the tracked object box

Wave

The Wave effect distorts the image into a wave-like pattern, simulating effects like heat haze, water reflections, or other forms of distortion. The speed, amplitude, and direction of the waves can be adjusted.

Property Name

Description

amplitude

(float, 0 to 5) The height of the wave

multiplier

(float, 0 to 10) Amount to multiply the wave (make it bigger)

shift_x

(float, 0 to 1000) Amount to shift X-axis

speed_y

(float, 0 to 300) Speed of the wave on the Y-axis

wavelength

(float, 0 to 3) The length of the wave

Audio Effects

Audio effects modify the waveforms and audio sample data of a clip. Below is a list of audio effects, and their properties. Often it is best to experiment with an effect, entering different values into the properties, and observing the results.

Compressor

The Compressor effect in audio processing reduces the dynamic range of the audio signal, making loud sounds quieter and quiet sounds louder. This creates a more consistent volume level, useful for balancing the loudness of different audio sources or for achieving a particular sound characteristic in music production.

Property Name

Description

attack

(float, 0.1 to 100)

bypass

(bool)

makeup_gain

(float, -12 to 12)

ratio

(float, 1 to 100)

release

(float, 10 to 1000)

threshold

(float, -60 to 0)

Delay

The Delay effect adds an echo to the audio signal, repeating the sound after a short delay. This can create a sense of space and depth in the audio, and is commonly used for creative effects in music, sound design, and audio post-production.

Property Name

Description

delay_time

(float, 0 to 5)

Distortion

The Distortion effect intentionally clips the audio signal, adding harmonic and non-harmonic overtones. This can create a gritty, aggressive sound characteristic of many electric guitar tones and is used for both musical and sound design purposes.

Property Name

Description

distortion_type

(int, choices: ['Hard Clipping', 'Soft Clipping', 'Exponential', 'Full Wave Rectifier', 'Half Wave Rectifier'])

input_gain

(int, -24 to 24)

output_gain

(int, -24 to 24)

tone

(int, -24 to 24)

Echo

The Echo effect, similar to delay, repeats the audio signal at intervals, but with a focus on creating a distinct repetition of sound that mimics natural echoes. This can be used to simulate acoustic environments or for creative sound effects.

Property Name

Description

echo_time

(float, 0 to 5)

feedback

(float, 0 to 1)

mix

(float, 0 to 1)

Expander

The Expander effect increases the dynamic range of audio, making quiet sounds quieter and leaving loud sounds unaffected. This is the opposite of compression and is used to reduce background noise or increase the dynamic impact of audio.

Property Name

Description

attack

(float, 0.1 to 100)

bypass

(bool)

makeup_gain

(float, -12 to 12)

ratio

(float, 1 to 100)

release

(float, 10 to 1000)

threshold

(float, -60 to 0)

Noise

The Noise effect adds random, equal-intensity signals across the frequency spectrum to the audio, simulating the sound of white noise. This can be used for sound masking, as a component in sound design, or for testing and calibration purposes.

Property Name

Description

level

(int, 0 to 100)

Parametric EQ

The Parametric EQ (Equalizer) effect allows for precise adjustments to the volume level of specific frequency ranges in the audio signal. This can be used for corrective measures, such as removing unwanted tones, or creatively, to shape the tonal balance of the audio.

Property Name

Description

filter_type

(int, choices: ['Low Pass', 'High Pass', 'Low Shelf', 'High Shelf', 'Band Pass', 'Band Stop', 'Peaking Notch'])

frequency

(int, 20 to 20000)

gain

(int, -24 to 24)

q_factor

(float, 0 to 20)

Robotization

The Robotization effect transforms the audio to sound mechanical or robotic, by applying a combination of pitch modulation and synthesis techniques. This effect is widely used for character voices in media, creative music production, and sound design.

Property Name

Description

fft_size

(int, choices: ['128', '256', '512', '1024', '2048'])

hop_size

(int, choices: ['1/2', '1/4', '1/8'])

window_type

(int, choices: ['Rectangular', 'Bart Lett', 'Hann', 'Hamming'])

Whisperization

The Whisperization effect transforms the audio to mimic a whispering voice, often by filtering out certain frequencies and adding noise. This can be used for artistic effects in music, sound design for film and video, or in audio storytelling to convey secrecy or intimacy.

Property Name

Description

fft_size

(int, choices: ['128', '256', '512', '1024', '2048'])

hop_size

(int, choices: ['1/2', '1/4', '1/8'])

window_type

(int, choices: ['Rectangular', 'Bart Lett', 'Hann', 'Hamming'])

For more info on key frames and animation, see Animation.
